Ubiquiti Networks 10G PoE+++ Adapter | 90W | UACC-PoE+++-10G

The Ubiquiti Networks 10G PoE+++ Adapter delivers up to 90W of power with Multi-Gigabit connectivity, eliminating the need for costly switch upgrades. This industrial-grade injector combines high-capacity power delivery and 10G data transmission in a compact form factor, protected by comprehensive surge and overcurrent safeguards. Ideal for demanding UniFi devices in enterprise and consumer networks requiring reliable, uninterrupted performance.

Features
High-Capacity Power Delivery: Supplies up to 90W of robust PoE+++ power to easily support resource-heavy UniFi devices.
Multi-Gigabit Connectivity: Features high-speed data transmission capabilities up to 10G to prevent network bottlenecks.
Comprehensive Electrical Shielding: Protects sensitive infrastructure with built-in surge, peak pulse, and overcurrent protection.
Versatile Deployment Options: Seamlessly supports wall, DIN rail, and floating mounting configurations (DIN rail and floating mounts sold separately).
Real-Time Monitoring: Includes an intuitive LED status indicator for instant visual network diagnostics.

Specifications
Output Voltage: 54V DC @ 1.67A
Rated Voltage: 100–240V AC @ 50/60Hz
Input Current: 1.5A Max
Inrush Current: <120A peak @ 230V AC
Efficiency: >88%
Switching Frequency: 65 kHz
Output Ripple: 1% Max
Line Regulation: ≤ 2%
Load Regulation: ≤ 5%
Max. PoE+ Wattage per Port by PSE: 90W
Max. Surge Discharge: 1500A (8/20 μs) power
Peak Pulse Current: 36A (10/1000 μs) data
Response Time: <1 ns
Shunt Capacitance: <5 pF data
Clamping Protection: 11V data, 60V power
4-Pair Powering Pins: Pins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-)
Data In / PoE: RJ45 shielded socket
Gigabit LAN Port: Yes
Certifications: CE, FCC, IC, UL, UKCA, KC, CCC, RoHS
NDAA Compliant: Yes
Ambient Operating Temperature: 0 to 40°C (32 to 104°F)
Ambient Operating Humidity: 10 to 95% noncondensing
Dimensions (L x W x H): 6.5 x 2.8 x 1.7 inches
Weight: 0.82 lbs
