TP-Link TL-POE10R PoE Splitter

The TP-Link TL-POE10R PoE Splitter offers reliable power over ethernet for a range of compatible devices. It's fully compliant with IEEE 802.3af standards and delivers 12V, 9V and 5V direct current at Gigabit speeds. With no configuration needed, you can quickly plug and play this reliable power source.

Interface

2 10/100/1000Mbps RJ45 Port
AUTO Negotiation/AUTO MDI/MDIX
1 POWER OUTPUT PORT (5.5 mm round barrel)


Network Media

10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)
100BASE-TX: UTP category 5, 5e cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)


1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)
Power Supply: 12VDC 1A, 9VDC 1A, 5VDC 2A selectable
Basic Function

Compatible With IEEE 802.3af Compliant PSEs
Delivers Power Up To 100 Meters
Selectable 12VDC, 9VDC or 5VDC power output
LED Indicator: PWR
Dimensions ( W x D x H )    3.2 × 2.1 × 0.9 in. (81 × 54 × 24 mm)
Certification: FCC, RoHS


Package Contents

PoE Splitter TL-POE10R
Power Cord
RJ45 Cable
Installation Guide


Environment

Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
