Features
Integrated 8-Port PoE Switch: Simplify camera deployment with 8 independent, plug-and-play PoE interfaces supporting IEEE 802.3af/at standards (up to 30W per port, 75W total).
High-Efficiency Ultra 265 Compression: Reduce storage costs and network bandwidth consumption by up to 75% compared to conventional H.264 without sacrificing image clarity.
Intelligent Deep-Learning Analytics: Run 2-channel Smart Intrusion Prevention (SIP) and 4-channel Ultra Motion Detection (UMD) directly from the NVR, filtering out false triggers caused by leaves, rain, or small animals to focus on humans and motor vehicles.
Dual Simultaneous Video Outputs: Display independent or mirrored live feeds on local monitors using simultaneous HDMI (up to 4K resolution) and VGA (up to 1080p) ports.
Ultra-HD 12MP Recording & Decoding: Record pristine surveillance footage with support for up to 12MP resolutions, capable of decoding 2 channels of 4K@30fps or 8 channels of 1080P@30fps.
ANR Failover Storage Architecture: Enhance overall system reliability by automatically synchronizing video footage recorded to camera SD cards during network outages as soon as connectivity restores.
Broad Interoperability & Cloud Management: Seamlessly integrate third-party cameras via ONVIF (Profile S, G, T) and RTSP protocols, and maintain effortless maintenance through one-click cloud firmware upgrades.
Specifications
IP Video Channels: 8 channels
Bandwidth: 80 Mbps incoming bandwidth / 80 Mbps outgoing bandwidth
Video Formats: Ultra 265, H.265, H.264
Recording Resolutions: 12MP, 8MP (4K), 6MP, 5MP, 4MP, 3MP, 1080P, 960P, 720P, D1, 2CIF, CIF
Decoding Capability:
Smart Off: 2 x 12MP@30, 2 x 4K@30, 4 x 4MP@30, 8 x 1080P@30
Smart On: 2 x 4K@30, 4 x 4MP@30, 8 x 1080P@30
Video Outputs:
1 x HDMI (4K 3840x2160/30Hz, 1080p/60Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz)
1 x VGA (1920x1080p/60Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz)
Audio Compression: G.711A, G.711U
Audio Interfaces: 1-ch RCA Input, 1-ch RCA Output (Two-way audio supported)
Concurrent Playback: Up to 16 channels
AI & Smart Features (NVR-based): 2-ch Smart Intrusion Prevention (SIP), 4-ch Ultra Motion Detection (UMD)
IPC-Assisted Analytics: Face Detection, Vehicle Detection, People Counting, Crowd Density Monitoring, Traffic Monitoring, Heat Map, Search by Image
Hard Drive Storage: 1 SATA interface supporting up to 10TB capacity
Network Interfaces: 1 x RJ45 10M/100M self-adaptive Ethernet
PoE Interfaces: 8 x RJ45 10M/100M self-adaptive Ethernet (IEEE 802.3af/at)
PoE Power Budget: Max 30W for a single port, Max 75W total
USB Connectivity: 1 x USB 2.0 (Rear), 1 x USB 3.0 (Rear)
Network Protocols: TCP/IP, P2P, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, RTSP, IPv6, IPv4, ONVIF (Profile S, G, T)
Remote Access: Supports up to 128 remote users; web viewing via Edge, Chrome, Firefox, IE
Power Supply: DC 52V / 1.8A
Power Consumption: ≤ 12W (without HDD)
Operating Temperature: -10°C to +55°C (+14°F to +131°F)
Operating Humidity: ≤ 90% RH (non-condensing)
Chassis Form Factor: 1U
Certifications: CE (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035), FCC (Part 15 Subpart B), UL, RoHS, WEEE
Dimensions (L x W x H): 10.2 x 8.7 x 1.8 inches
Weight: ≤ 6 lbs
