Features
24/7 Full-Color Surveillance (ColourHunter & Wise-ISP): Captures vivid, detailed color footage day and night using an F1.0 large aperture lens, a 1/1.8" CMOS sensor, and soft warm supplemental lighting effective up to 98.4 ft (30 m).
True 120 dB WDR: Balances intensely backlit scenes and deep shadows simultaneously, preventing silhouetting and preserving forensic details across glass lobbies, gates, and storefronts.
Smart Human Body Analytics: Reduces nuisance alarms by prioritizing events with AI-powered perimeter protection, including Cross Line and Intrusion detection calibrated specifically for human targets.
Integrated Audio Capture: Features a built-in microphone with environmental noise suppression to provide synchronized audio-visual verification without running separate audio wiring.
Bandwidth & Storage Optimization: Employs Ultra 265 and smart U-code compression alongside standard H.265/H.264 codecs to reduce network load and NVR storage consumption by up to 75%.
Rugged All-Metal, Weatherproof Build: Boasts an IP67 ingress protection rating, 4 KV surge resistance, and an operating temperature range of -22 °F to 140 °F (-30 °C to 60 °C).
Flexible 3-Axis Turret Design: Enables precise manual aiming with 360° pan, 75° tilt, and 360° rotation for rapid wall, ceiling, or soffit deployment.
Broad Enterprise Compatibility: Operates smoothly with UNV-Link, EZStation, and third-party VMS platforms via ONVIF (Profile S, Profile G, Profile T) compliance.
Specifications
Image Sensor: 1/1.8" Progressive Scan CMOS
Max Resolution: 4 Megapixel (2688 × 1520)
Lens / Focal Length: 2.8 mm @ F1.0 (Fixed Iris)
Field of View (FOV): Horizontal: 110.4°, Vertical: 60.5°, Diagonal: 115.2°
Minimum Illumination: Color: 0.0003 Lux (F1.0, AGC ON); 0 Lux with warm light
Supplemental Illumination: Warm white light; up to 98.4 ft (30 m) range (Auto/Manual)
Shutter Speed: Auto/Manual, 1 s to 1/100,000 s
Wide Dynamic Range: 120 dB True WDR
Noise Reduction: 2D / 3D Digital Noise Reduction (DNR)
DORI Distances: Detect: 142.4 ft (43.4 m): Observe: 57.1 ft (17.4 m): Recognize: 28.5 ft (8.7 m): Identify: 14.1 ft (4.3 m)
Main Stream Frame Rates: 4MP (2688 × 1520) @ 25/20 fps; 4MP (2560 × 1440) @ 25/20 fps; 3MP (2304 × 1296) @ 30/25 fps; 1080P @ 30/25 fps
Sub Stream Frame Rates: 720P (1280 × 720), D1 (720 × 576), 640 × 360 @ max 30 fps
Video Compression: Ultra 265, H.265, H.264 (Baseline/Main/High Profile), MJPEG
Video Bitrate Range: 128 Kbps to 6144 Kbps
Audio Interface & Codecs: Built-in microphone; G.711U, G.711A (8 kHz sampling rate, 64 Kbps bitrate)
Smart Analytics: Human-body-based Cross Line & Intrusion detection, Ultra Motion Detection, Tampering Alarm, Audio Detection
Edge Storage: MicroSD card slot, supports up to 512 GB; ANR; NAS (NFS)
Network Protocols: IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS
Integration Standards: ONVIF (Profile S, Profile G, Profile T), API, SDK
Power Supply & Draw: DC 12 V ± 25%, PoE (IEEE 802.3af); Max power consumption: 2.8 W
Interface: 1 × RJ45 10M/100M Base-TX Ethernet; Ø5.5 mm coaxial DC power plug
Housing & Ingress Rating: Metal construction; IP67 weather resistance
Surge Protection: 4 KV
Operating Temperature: -22 °F to 140 °F (-30 °C to 60 °C); Humidity: ≤ 95% RH (non-condensing)
Regulatory & Compliance: FCC (Part 15 B), CE-EMC, CE LVD, UL/CUL (UL 62368-1), RoHS, WEEE, NDAA Compliant
Dimensions (L x W x H) (inches): 4.6" × 4.6" × 4.2"
Weight (lbs): 1.11 lbs
