Features
Intelligent Dual-Light Illumination: Integrates both 850 nm Smart IR and supplemental warm light up to 98.4 ft (30 m), providing flexible black-and-white night vision or full-color capture on demand.
4MP High-Definition Imaging: Captures crystal-clear 2560 × 1440 resolution video at up to 25 fps, powered by a wide-aperture F1.6 2.8 mm fixed lens with a broad 95.1° horizontal field of view.
Ultra 265 Bandwidth Optimization: Employs advanced Ultra 265 and H.265 compression protocols to slash network bandwidth consumption and storage requirements by up to 75% without compromising image fidelity.
Built-in Audio Monitoring: Features an integrated microphone with audio suppression and detection capabilities, adding critical situational sound context to your video recordings.
Smart Motion & Event Detection: Supports Ultra Motion Detection (UMD), tampering alerts, and audio alarms to proactively alert security operators and minimize false notifications.
Rugged Weatherproof Construction: Boasts an IP67-rated metal and plastic housing with 4 KV surge protection, engineered to operate seamlessly in temperatures ranging from -22 °F to 140 °F (-30 °C to 60 °C).
High-Capacity Edge Storage: Houses an onboard MicroSD slot supporting cards up to 512 GB for dependable local backup and standalone recording redundancy.
Versatile 3-Axis Adjustment & Corridor Mode: Allows complete 360° pan/rotation and 80° tilt adjustment, complemented by 9:16 corridor mode to efficiently monitor narrow hallways and aisles.
Specifications
Camera & Optics
Image Sensor: 1/3.0", 4.0 megapixel, progressive scan, CMOS
Max Resolution: 4MP (2560 × 1440)
Minimum Illumination: Color: 0.01 Lux (F1.6, AGC ON); 0 Lux with IR on
Day/Night: IR-cut filter with auto-switching (ICR)
Shutter Speed: Auto/Manual, 1 ~ 1/100,000s
Focal Length: 2.8 mm @ F1.6 (Fixed Iris)
Angle of View: 95.1° (Horizontal) / 51.6° (Vertical) / 111.6° (Diagonal)
DORI Distance (2.8 mm): Detect: 206.7 ft (63.0 m) | Observe: 82.7 ft (25.2 m) | Recognize: 41.3 ft (12.6 m) | Identify: 20.7 ft (6.3 m)
Camera Angle Adjustment: Pan: 0° to 360° | Tilt: 0° to 80° | Rotate: 0° to 360°
Signal-to-Noise Ratio (S/N): >52 dB
Dynamic Range: Digital WDR (DWDR)
Illuminator
Supplemental Light Type: Dual Light (Smart IR & Warm White Light)
IR Illumination Distance: Up to 98.4 ft (30 m)
Warm Light Distance: Up to 98.4 ft (30 m)
IR Wavelength: 850 nm
Control: Auto / Manual
Video & Image Management
Video Compression: Ultra 265, H.265, H.264 (Baseline, Main, High Profiles), MJPEG
Frame Rates:
Main Stream: 4MP (2560 × 1440) @ max 25 fps; 3MP (2304 × 1296) @ max 30 fps; 1080P (1920 × 1080) @ max 30 fps; 720P @ max 30 fps
Sub Stream: D1 (720 × 576), 640 × 360, 2CIF, CIF @ max 30 fps
Video Bitrate: 128 Kbps to 6144 Kbps (Supports U-code)
Image Enhancements: 2D/3D DNR, Highlight Compensation (HLC), Backlight Compensation (BLC), Digital Defog
Privacy Masking & OSD: Up to 4 privacy mask areas; up to 4 OSDs; ROI supported
Image Orientation: Normal, Flip Vertical, Flip Horizontal, 180°, 90° Clockwise (Corridor Mode), 90° Anti-clockwise
Audio & Detection
Audio Compression: AAC-LC (128 kbps), G.711U/G.711A (64 kbps)
Audio Sampling Rates: G.711: 8 kHz; AAC-LC: 8 kHz, 16 kHz, 48 kHz
Built-in Hardware: Integrated microphone (Two-way audio not supported; Built-in speaker N/A)
Event Triggers: Motion detection, Ultra Motion Detection (UMD), Tampering alarm, Audio detection
Storage & Network
Edge Storage: MicroSD card slot up to 512 GB
Network Storage: ANR, NAS (NFS)
Protocols: IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL/TLS, SNMP
API & System Integration: ONVIF (Profile S, Profile G, Profile T), SDK, API
Network Interface: 1 × RJ45 10M/100M Base-TX Ethernet
Security: Password protection, HTTPS encryption, RTSP/HTTP Digest authentication, TLS 1.2, IP address filtering
Power Supply: DC 12V ± 25%, PoE (IEEE 802.3af)
Power Consumption: Max. 2.8 W
Power Connector: Ø5.5 mm coaxial power plug
Ingress Protection: IP67 (IEC 60529)
Surge Protection: 4 KV
Operating Conditions: -22 °F to 140 °F (-30 °C to 60 °C), Humidity: ≤ 95% RH (non-condensing)
Housing Material: Metal + Plastic composite
Product Dimensions (L × W × H): 4.6" × 4.6" × 3.9"
Weight: 0.69 lbs
