Features & Functional Benefits
Next-Gen Wi-Fi 7 Speeds: Delivers up to 6.5 Gbps across tri-band connections (2882 Mbps on 6 GHz + 2882 Mbps on 5 GHz + 688 Mbps on 2.4 GHz) to eliminate bandwidth bottlenecks.
Multi-Link Operation (MLO): Dynamically utilizes multiple wireless bands simultaneously to reduce latency, boost throughput, and ensure seamless network stability.
Integrated Bluetooth 5.4: Features the latest high-speed Bluetooth standard, providing enhanced security, reliability, and smooth interoperability with controllers, headphones, and peripherals.
Broader Antenna Coverage: Equipped with two external high-gain tri-band antennas to extend Wi-Fi coverage and maintain strong signal integrity from farther away.
Optimized Congestion Control: Combines 4K-QAM, OFDMA, and MU-MIMO technologies to handle multiple device data streams concurrently without lag.
Robust Cyber Security: Leverages WPA3 security protocols to deliver enhanced encryption and brute-force protection for sensitive network traffic.
Flexible PC Chassis Fit: Includes both full-height standard and low-profile brackets to fit standard tower cases and small-form-factor (SFF) builds.
Technical Specifications
Wireless Standards: IEEE 802.11a/b/g/n/ac/ax/be (Wi-Fi 7)
Bluetooth Version: Bluetooth 5.4
Maximum Data Rates:
6 GHz: Up to 2882 Mbps
5 GHz: Up to 2882 Mbps
2.4 GHz: Up to 688 Mbps
Key Wireless Technologies: Multi-Link Operation (MLO), 4K-QAM, Multi-RUs, OFDMA, MU-MIMO
Wireless Security: WPA / WPA2 / WPA3, WPA-PSK / WPA2-PSK
Antennas: 2× External High-Performance Tri-Band Antennas
Interface: PCI Express (PCIe)
Transmit Power: 24 dBm (FCC) / 20 dBm (CE)
Supported Operating System: Windows 11 (64-bit) only
Included Package Accessories: Archer TBE400E Adapter, 2× Tri-Band Antennas, Low-Profile Bracket, Bluetooth Header Cable, Quick Installation Guide, Resource CD
Regulatory Certifications: FCC, CE, IC, NCC, JRF, VCCI, BSMI
Dimensions (L × W × H): 4.80 × 3.09 × 0.85 inches
