Features:
Simultaneous Quad Display: Distributes one HDMI input source to four individual HDMI TVs, monitors, or projectors at the same time without dropping frames.
Active Signal Regeneration: Re-clocks and boosts high-definition digital signals, letting you run input cables up to 15 meters and output lines up to 25 meters (using standard AWG26 cabling).
Lossless Quality Transmission: Maintains pristine pixel-for-pixel accuracy, delivering uncompressed digital video and crisp multichannel audio streams.
Heavy-Duty Isolation: Built with premium internal architecture to withstand continuous multi-display operational strains in retail, sports bars, data centers, or corporate boardrooms.
Specifications:
Video Resolution Support: Full HD 1080p, 1080i, 720p, 720i, 576p, 576i, 480p, 480i
3D Architecture: Fully compliant with all standard high-definition Full 3D video formats
Max Bandwidth: 340MHz
Max Baud Rate: 10.2 Gbps data transfer speed
Color Profile Depth: Supports ultra-rich Deep Color matrixes (30-bit, 36-bit, and 48-bit)
Digital Audio Formats: Master-class pass-through for DTS-HD, Dolby-True HD, LPCM 7.1, DTS, Dolby-AC3, and DSD/HD (HBR)
Media Source Compliance: Advanced support for Blu-Ray 24/50/60fs, HD-DVD, and xvYCC color spaces
Power Supply: Includes dedicated DC 5V External Power Adapter for continuous operational stability
Dimensions (L x W x H) (inches): 7.0" x 2.4" x 0.8"
Shipping Dimensions (L x W x H) (inches): 8.0" x 6.0" x 2.0"
Weight (lbs): 1.02 lbs
