Manhattan 7-Port USB 3.0 Type-C / Type-A Combo Hub 3+4 (181136)

The Manhattan 7-Port USB 3.0 Type-C / Type-A Combo Hub 3+4 (181136) converts a single USB port into three USB-C and four USB-A ports, enabling connection of multiple devices like keyboards, mice, flash drives, and phones. Supporting USB 3.2 Gen 1 with transfer speeds up to 5 Gbps, it ensures fast data exchange and backward compatibility with USB 2.0 and 1.1. The bus-powered hub delivers up to 7.5 W for charging mobile devices and features both USB-C and USB-A male connectors for versatile compatibility. Its compact aluminum design is ideal for desktops, laptops, and travel, requiring no drivers for plug-and-play use.

Features
Adds three USB-C and four USB-A ports to connect mice, keyboards, flash drives and more or to charge and sync mobile devices
USB 3.2 Gen 1 (formerly USB 3.0) USB ports with SuperSpeed transfer rates up to 5 Gbps and charging up to 7.5 W (5 V / 1.5 A)
2-in-1 combo cable with USB-C and USB-A plugs
Great for desktop PCs, Ultrabooks™, laptops, Chromebooks™, MacBooks®, Surface® devices and more
Compatible with Windows®, macOS®, Linux® and Chrome OS™
Plug-and-play installation; no configuration or drivers required
Bus powered, external power supply optional
Optional 5 V / 4 to 6 A USB-C jack to connect included 20 W power adapter for maximum power on all USB output ports
Backward compatible with USB 2.0 and USB 1.1
Supports Hot Swapping
Built-in, sturdy 30 cm (1 ft.) cable
Sleek aluminum housing with small footprint, great for desktop placement and travel
Portable, compact and lightweight design that easily fits into laptop bag pockets
Three-year warranty

Specifications
Standards and Certifications
USB 3.2 Gen 1 (USB 3.0)
FCC

General
Data transfer speeds: 5 Gbps
USB charging power output:
- 4.5 W (5.0 V at 0.9 A) max. with bus power
- 7.5 W (5.0 V at 1.5 A) max. with connected 20 W power adapter
Withstanding voltage: 300.0 V DC
Insulation resistance: 10 MΩ
Conductive resistance: 5 Ω

Connections
One USB-C 24-pin, male
One USB-A 9-pin, male
Four USB-A 9-pin, female
Three USB-C 24-pin, female
One USB-C 6-pin, female (optional input power port, 5.0 V, 3.0 - 6.0 A, 20.0 W)

Physical
Dimensions (L x W x H): 138 x 32 x 19 mm (5.43 x 1.26 x 0.75 in.)
Net weight: 193 g (0.43 lbs.)
Gross weight: 250 g (0.55 lbs.)
Cable length: 30 cm (1 ft.)
Cable OD: 4.5 mm (0.18 in.)
Housing: aluminum

Operating Environment
Operation Temperature: 0 - 50°C (32 – 122°F)
Storage Temperature: -20 - 60°C (-4 – 140°F)
Humidity (non-condensing): 30 - 85%

System Requirements
Windows XP/Vista/7/8.1/10/11, Linux, Chrome OS or macOS

Package Contents
7-Port 3xUSB-C / 4xUSB-A Hub with Type-C/Type-A combo plug
Optional power adapter, AC to USB-C, 20.0 W/4.0 A, 1 m (3 ft.) cable
Instructions
