Features
4MP High-Definition Video: Captures high-clarity 2560 x 1440 surveillance video at a fluid 30 frames per second for actionable forensic evidence.
4X Motorized Optical Zoom: Adjust focal length from 2.8 mm wide-angle coverage (99.4° FOV) to 12 mm telephoto magnification (32.8° FOV) quickly and remotely.
Intelligent Deep-Learning Analytics: Reduces false triggers by accurately distinguishing between humans, vehicles, and irrelevant environmental motion.
Two-Way Audio Communication: Features a built-in microphone (5-meter pickup radius) and integrated high-output speaker (10-meter effective distance) for active verbal deterrence.
120 dB True WDR & Low-Light Sensitivity: Delivers crisp color rendition in scenes as low as 0.005 Lux and balances severe contrast between bright exterior windows and dark interiors.
20-Meter Smart IR Night Vision: Automatically modulates 850 nm infrared illumination to eliminate foreground overexposure in pitch darkness.
Industrial-Grade Durability: Built tough with IP66 dust-and-water protection, IK10 vandal resistance, and 4000V TVS surge protection to withstand outdoor abuse.
Flexible Power Delivery: Powers via single-cable Power over Ethernet (PoE 802.3af) or standard 12 VDC local input for streamlined, cost-effective deployments.
Specifications
Image Sensor: 1/2.8" Progressive Scan CMOS
Maximum Resolution: 4 MP (2560 × 1440)
Frame Rate: 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720); 50 Hz: 25 fps
Minimum Illumination: Color: 0.005 Lux @ (F1.8, AGC ON); B/W: 0.001 Lux @ (F1.8, AGC ON); 0 Lux with IR
Shutter Speed: 1/1 s to 1/30,000 s (Slow Shutter supported)
Focal Length & Lens Type: 2.8 mm to 12 mm motorized varifocal lens; 4x optical zoom, 16x digital zoom
Aperture: Max. F1.8
Field of View (FOV): Horizontal: 99.4° to 32.8°; Vertical: 51.7° to 18.4°; Diagonal: 119.9° to 37.5°
PTZ Movement Range: Pan: 0° to 355°; Tilt: 0° to 90°
PTZ Speeds: Pan: configurable 0.1° to 50°/s (Preset speed: 50°/s); Tilt: configurable 0.1° to 50°/s (Preset speed: 50°/s)
Presets & Functions: 300 Presets, Patrol Scan, Preset Freezing, 3D Positioning, Power-off Memory
Supplement Light: Infrared (IR), 850 nm wavelength; range up to 20 m (65.6 ft)
Wide Dynamic Range (WDR): 120 dB True WDR
Image Enhancements: 3D DNR, BLC, HLC, Digital Defog, Regional Focus, Regional Exposure
Video Compression: Main Stream: H.265+ / H.265 / H.264+ / H.264; Sub-Stream: H.265 / H.264 / MJPEG
Audio Input/Output: 1 built-in microphone, 1 built-in speaker; 1 audio line-in (2–2.4 Vpp), 1 audio line-out (600 Ω)
Audio Compression: G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM, AAC
On-Board Storage: MicroSD / microSDHC / microSDXC slot supporting cards up to 512 GB
Network Storage: NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Interoperability (API): ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
Smart Events: Line crossing detection, intrusion detection, region entrance detection, region exiting detection
Operating Conditions: -20°C to 60°C (-4°F to 140°F); Humidity: ≤ 90% (non-condensing)
Power Requirements: 12 VDC, Max. 9.2 W; PoE (802.3af)
Ingress & Impact Ratings: IP66 (IEC 60529-2013), IK10, TVS 4000V lightning, surge, and transient protection
Product Dimensions (Diameter x Height): Ø 5.15" x 4.00"
Product Weight: Approx. 1.26 lbs
Shipping Package Weight: Approx. 1.83 lbs
