Features
InVid Illuminate™ Full-Color Night Vision: Captures rich, vivid color video 24/7 in conditions down to 0.0001 Lux without relying on external white light.
True AI Human & Vehicle Classification: Optimizes edge intelligence to prevent false alarms with targeted line crossing and region intrusion analytics.
Discreet Black Weatherproof Housing: Features a low-profile black finish and durable IP67 weatherproof construction to blend into dark exteriors while resisting harsh elements.
Streamlined PoE Connectivity: Eliminates complex wiring by running both power and high-speed data over a single network cable.
Expansive Edge Storage: Features an integrated micro SD slot supporting up to 512GB of onboard backup storage.
Instant P2P QR Code Connection: Simplifies remote setup through a quick mobile scan, giving you instant access to free iOS, Android, and Mac/PC central software.
Specifications
Image Sensor: 1/1.79" CMOS
Max Resolution: 4MP (2688 × 1520) @ 30 FPS
Lens Parameters: 2.8mm fixed lens (Horizontal FoV: 112°, Vertical FoV: 61°, Diagonal FoV: 132°)
Minimum Illumination: 0.0001 lux @ F1.0 (AGC ON); 0 lux with illumination on
Wide Dynamic Range: 120dB (supported in upcoming version)
Video Compression Standard: Main Stream: H.265+, H.265, H.264+, H.264; Sub/Third Stream adds MJPEG
Video Bit Rate: 32 Kbps to 8 Mbps (VBR / CBR)
Audio Interfacing: 1-channel audio input and 1-channel built-in microphone (G.711A / U compression)
Intelligent Analytics: Line crossing, region intrusion/entrance/exiting (with human/vehicle classification), abandoned/missing object, target counting, face detection, and face capture
Network Protocols: UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, FTP, PPPoE, DDNS, SMTP, SNMP, HTTP, 802.1x, UPnP, HTTPS, P2P, QoS
Interface Protocol: ONVIF (Profile G/S/T/M)
Power Supply Requirement: DC12V or PoE (IEEE802.3af)
Power Consumption: < 6.5W
Operating Conditions: -22°F to 140°F (-30°C to 60°C) | Humidity: ≤ 95% (non-condensing)
Certifications & Compliance: NDAA Compliant, CE, FCC, EU RoHS, WEEE, REACH
Dimensions (L x W x H) (inches): Ø 4.4" x 3.9" (Ø 111.6mm × 99.6mm)
Net Weight: Approx. 1.45 lbs
