Features
InVid Illuminate™ Full-Color Night Vision: Captures vivid, detailed color video 24/7 in extreme low light (0.0001 Lux) without mandatory white light. Includes a 98-foot white light backup option for specialized needs.
True AI Human & Vehicle Classification: Boosts security efficiency by targeting analytics to isolate line crossing and region intrusion events while filtering out environmental noise.
Seamless Plug-and-Play PoE: Runs power and high-speed video data through a single network cable, simplifying installation layouts for quick deployments.
Massive Onboard Edge Storage: Features an integrated micro SD slot supporting up to 512GB of local backup storage to prevent data loss during network interruptions.
Weatherproof & Resilient Build: Certified with an IP67 weatherproof rating, ensuring uninterrupted operation through severe weather conditions.
Instant QR Code P2P Setup: Simplifies remote viewing configurations via a quick mobile scan, providing instant access to free iOS, Android, and Mac/PC central software.
Specifications
Image Sensor: 1/1.79" CMOS
Max Resolution: 4MP (2688 × 1520) @ 30 FPS
Lens Parameters: 2.8mm fixed lens (Horizontal FoV: 112°, Vertical FoV: 61°, Diagonal FoV: 132°)
Minimum Illumination: 0.0001 lux @ F1.0 (AGC ON); 0 lux with illumination on
S/N Ratio: ≥50dB
Wide Dynamic Range: 120dB (Supported in upcoming version)
Image Enhancement: BLC, HLC, Defog, 3D DNR, EIS
Adjustment Angles: Pan: 0°~360°; Tilt: 0°~80°; Rotation: 0°~360°
Video Compression Standard: Main Stream: H.265+, H.265, H.264+, H.264; Sub/Third Stream adds MJPEG
Video Bit Rate: 32 Kbps to 8 Mbps (VBR / CBR)
Audio Interfacing: 1-channel audio input and 1-channel built-in microphone (G.711A / U compression) with audio exception detection
Intelligent Analytics: Line crossing, region intrusion/entrance/exiting (with human/vehicle classification), abandoned/missing object detection, target counting, face detection, and face capture
Network Protocols: UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, FTP, PPPoE, DDNS, SMTP, SNMP, HTTP, 802.1x, UPnP, HTTPS, HTTP POST, P2P, QoS
Interface Protocol: ONVIF (Profile G/S/T/M)
Power Supply Requirement: DC12V or PoE (IEEE802.3af)
Power Consumption: < 6.5W
Operating Conditions: -22°F to 140°F (-30°C to 60°C) | Humidity: ≤ 95% (non-condensing)
Certifications & Compliance: NDAA Compliant, CE, FCC, EU RoHS, WEEE, REACH
Dimensions (L x W x H) (inches): Ø 4.4" x 3.9" (Ø 111.6mm × 99.6mm)
Net Weight: Approx. 1.54 lbs
