GIGABYTE B850 GAMING X WIFI6E ATX Motherboard | AMD AM5 | DDR5 8200+ | PCIe 5.0 | 2.5G LAN

The GIGABYTE B850 GAMING X WIFI6E delivers enterprise-grade power delivery through its 12*+2+2 Twin Digital VRM architecture and 6-layer PCB, ensuring rock-solid stability for AMD Ryzen 7000, 8000, and 9000 Series processors on the AM5 socket. This ATX platform harnesses PCIe 5.0 bandwidth for next-generation graphics and NVMe storage, while DDR5 support up to 8200 MT/s (with AMD EXPO) enables aggressive memory overclocking. X3D Turbo Mode provides instant gaming performance optimization, complemented by dual 2.5GbE LAN and Wi-Fi 6E connectivity for minimal latency. Tool-free installation via EZ-Latch Plus and M.2 EZ-Latch Click streamlines system building, while comprehensive thermal management protects critical components during sustained workloads.

Features:
AMD Socket AM5: Supports AMD Ryzen™ 9000/8000/7000 Series Processors.
Power Design: 12*+2+2 Twin Digital VRM Design with 60A DrMOS and 6-Layer PCB for ultra-stable performance.
Next-Gen Connectivity: Includes PCIe 5.0 x16 slot and 3x M.2 slots (one supporting PCIe 5.0 x4).
Gaming Modes: Features X3D Turbo Mode for one-click gaming FPS boost.
Ultra-Fast Networking: Equipped with 2.5GbE LAN and Wi-Fi 6E for high-speed wireless and wired connections.
Memory Overclocking: Supports DDR5 memory speeds up to 8200 MT/s (O.C.) with AMD EXPO™ support.
Thermal Management: Comprehensive cooling with VRM Thermal Armor and M.2 Thermal Guard Ext.
DIY Friendly: Features EZ-Latch Plus (PCIe) and M.2 EZ-Latch Click for tool-less installation of graphics cards and SSD heatsinks.

Specifications:
Chipset: AMD B850
CPU Socket: Socket AM5
Form Factor: ATX
Memory (Max): 4 x DDR5 DIMM sockets, up to 256 GB, Dual Channel
LAN: Realtek® 2.5GbE LAN
Wireless: Realtek® Wi-Fi 6E (802.11ax) and Bluetooth 5.3
Audio: Realtek® Audio CODEC (High Definition, 7.1-channel support)
Expansion Slots: 1 x PCIe 5.0 x16, 2 x PCIe 3.0 x16 (running at x1 mode)
Storage: 3 x M.2 connectors (1x PCIe 5.0 x4, 2x PCIe 4.0 x4), 4 x SATA 6Gb/s connectors
Weight (lbs): 4.62 lbs
