Description
- ATX Form Factor
- Intel LGA1700 Socket
- Intel Z790 Chipset
- 4 x Memory Slots (DIMM/UDIMM)
- Up to 128GB DDR5 SDRAM Maximum RAM
- 2.5 Gigabit Ethernet
- WiFi 6E 802.11 a/b/g/n/ac/ax
- HDMI - DisplayPort
- 4 x SATA Interfaces
The ASUS ROG Strix Z790-H GAMING WIFI 6E LGA1700 Gaming Desktop Motherboard is a powerful choice for gamers. It's equipped with Intel 13th Gen processor support, four M.2 slots with a combo sink, PCIe 5.0 and WiFi 6E ready for next-gen GPU, and USB 3.2 Gen 2x2 for fast connection. Enjoy up to 128GB DDR5 SDRAM and 2.5 Gigabit Ethernet with quick setup.
- Manufacturer: ASUS ROG
- Part Number: ROG STRIX Z790-H GAMING WIFI
- Product Name: Strix Z790-H GAMING WIFI Gaming Desktop Motherboard
- Type: Gaming Desktop Motherboard
- Chipset Manufacturer: Intel
- Chipset Model: Z790
- Total Processor Supported: 1
- Processor Socket: Socket LGA-1700
- Processor Generation Supported: 13th Gen; 12th Gen
- Processor Supported: Celeron; Pentium Gold; Core
- Number of Memory Slots: 4
- Memory Form Factor: DIMM; UDIMM
- Maximum Memory Supported: 128 GB
- Memory Technology: DDR5 SDRAM
- Memory Speed Supported: 5200 MHz; 5400 MHz; 5800 MHz; 6000 MHz; 6200 MHz; 7800 MHz; 4800 MHz; 5000 MHz; 5600 MHz; 6400 MHz; 6600 MHz; 6800 MHz; 7000 MHz
- Controller Type: Serial ATA/600
- RAID Supported: Yes
- RAID Levels: 10; 5; 0; 1
- Onboard Video: CPU Dependent Video
- Audio Channels: 7.1
- Bluetooth: Yes
- Bluetooth Standard: Bluetooth 5.3
- Gigabit Ethernet: Yes
- 2.5Gigabit Ethernet: Yes
- Wireless LAN: Yes
- Wireless LAN Standard: IEEE 802.11 a/b/g/n/ac/ax
- Number of Total Expansion Slots: 3
- PCI Express Standard: PCI Express 3.0; PCI Express 4.0; PCI Express 5.0
- Total Number of PCI Express Slots: 3
- Number of PCI Express x1 Slots: 2
- Number of PCI Express x16 Slots: 1
- Total Number of USB Ports: 10
- Number of USB 3.2 Gen 1 Type-A Ports: 4
- Number of USB 3.2 Gen 2 Type-A Ports: 2
- Number of USB 3.2 Gen 2 Type-C Ports: 1
- S/PDIF: Yes
- HDMI: Yes
- HDMI Version: 2.1
- DisplayPort: Yes
- Number of Network (RJ-45) Ports: 1
- Thunderbolt: Yes
- Number of SATA Interfaces: 4
- Number of M.2 Interfaces: 4
- Total Number of Onboard USB Ports: 7
- Number of Onboard USB 2.0 Ports: 4
- Form Factor: ATX
- Width: 12"
- Depth: 9.6"
Package Contents
- Strix Z790-H GAMING WIFI Gaming Desktop Motherboard
- 2 x SATA 6Gb/s cables
- 1 x Thermal pad for M.2
- 1 x ASUS Wi-Fi moving antennas
- 1 x Cable ties package
- 1 x M.2 backplate Q-Latch package
- 1 x M.2 Q-Latch package
- 1 x ROG key chain
- 1 x ROG Strix stickers
- 1 x ROG Strix thank you card
- 2 x M.2 Rubber Packages
- 1 x M.2 backplate Rubber
- 1 x User guide
