Features
Ultrafast WiFi 7: 802.11be dual-band speeds up to 6500 Mbps with 4096-QAM.
Five 2.5GbE Ports: One 2.5G WAN port and four 2.5G LAN ports for high-speed wired connections.
Hassle-free AiMesh: Creates a seamless whole-home mesh network with other AiMesh-compatible routers.
Multi-link Operation (MLO): Links to multiple bands simultaneously for stable connections and efficient data transfers.
Commercial-Grade Network Security: Includes AiProtection Pro powered by Trend Micro™, a one-tap security scan, and Safe Browsing.
Network Segmentation: Easily create dedicated subnetworks for IoT devices, kids, or VPNs.
Advanced Parental Controls: Manage screen time and filter content with preset profiles and flexible scheduling.
Mobile Tethering: Supports 4G LTE & 5G mobile tethering via a USB port for backup internet.
Specifications
WiFi Standard: WiFi 7 (IEEE 802.11be)
Product Segment: BE6500 (688 Mbps on 2.4GHz + 5764 Mbps on 5GHz)
Modulation: 4K-QAM (4096-QAM)
Channels: 160 MHz
Ports:
1 x 2.5G WAN Port
4 x 2.5G LAN Ports
1 x USB 3.2 Gen 1
CPU: 2.0 GHz quad-core processor
RAM: 1 GB
Antennas: 4 x external antennas
Security: AiProtection Pro, WPA3-Personal, WPA/WPA2/WPA3-Enterprise, VPN (WireGuard, OpenVPN, IPSec)
Dimensions (WxDxH): 9.37" x 5.79" x 3.82" (238 x 147 x 97 mm)
Weight: 1.1 lbs (502g)
