Management features
Switch type: Managed
Quality of Service (QoS) support: Yes
Web-based management: Yes
System event log: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
Network
Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support: No
Cable types supported: Cat3, Cat4, Cat5, Cat5e
Port mirroring: Yes
Full duplex: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Rate limiting: Yes
Spanning tree protocol: Yes
Auto-negotiation: Yes
VLAN support: Yes
Data transmission
MAC address table: 8000 entries
Switching capacity: 52 Gbit/s
Forwarding rate: 1.488 Mpps
Store-and-forward: Yes
Jumbo frames support: Yes
Jumbo frames: 9216
Security
Access Control List (ACL): Yes
IGMP snooping: Yes
Authentication: Port-based authentication
Multicast features
Multicast support: Yes
Number of multicast groups filtered: 8
Design
Rack mounting: Yes
Form factor: 1U
Product color: Black
Housing material: Metal
LED indicators: Yes
Performance
Buffer size: 512 KB
Power
Power source: AC
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (max): 20 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Width: 17.3" (440 mm)
Depth: 8.07" (205 mm)
Height: 1.73" (44 mm)
Weight: 4.85 lbs (2.2 kg)
Packaging content
Cables included: AC
Manual: Yes
Rack mount kit: Yes
Packaging data
Mounting brackets included: Yes
Certificates
Certification: FCC Class A, CE
Logistics data
Harmonized System (HS) code: 85176990
