Features
Active Perimeter Deterrence: Ward off trespassers immediately using an integrated white strobe light and high-output audio alarm triggered upon perimeter breach.
Intelligent Deep Learning Analytics: Eliminate nuisance false alarms by classifying human and vehicle targets with precision filtering.
Smart Hybrid Lighting: Choose between covert infrared illumination, full-color supplemental white light (up to 98 ft / 30 m), or smart automatic switching when an event occurs.
Two-Way Audio & High-Gain Monitoring: Capture crisp ambient audio and communicate clearly with visitors via the built-in dual-array microphone and integrated speaker.
120 dB True WDR Performance: Neutralize difficult high-contrast lighting, glare, and bright backlighting to preserve sharp subject details.
H.265+ Bandwidth Optimization: Cut bandwidth consumption and storage footprint by up to 75% without compromising 4MP stream resolution.
Industrial Weather Resistance: Defend against severe outdoor conditions with an IP67-rated waterproof and dust-tight black aluminum enclosure.
Specifications
Image Sensor: 1/2.9" Progressive Scan CMOS
Max Resolution: 4MP (2560 × 1440) @ 20/30 fps
Lens / Focal Length: 2.8 mm Fixed Lens, F1.6 Aperture
Angle of View: Horizontal FOV: ~103°, Vertical FOV: ~58°, Diagonal FOV: ~123°
Supplemental Illumination: Smart Hybrid Light (Infrared IR + White Light LED)
Illumination Distance: Up to 98 ft (30 m)
Lighting Modes: IR Mode, White Light Mode, Smart Mode
Wide Dynamic Range (WDR): 120 dB True WDR
Audio Hardware: Built-in dual-array microphone and built-in speaker (Two-Way Audio supported)
Active Deterrence Hardware: Integrated flashing strobe light & audible siren/voice prompts
Video Compression: H.265+ / H.265 / H.264+ / H.264 / MJPEG
Edge Storage: MicroSD / MicroSDHC / MicroSDXC card slot up to 512 GB
Perimeter Analytics: Line crossing detection, intrusion detection, human and vehicle classification
Network Interface: 1 RJ45 10M/100M self-adaptive Ethernet port
Power Supply: 12 VDC ± 25% or Power over Ethernet (PoE 802.3af, Class 3)
Power Consumption: Max. 8.5 W (12 VDC) / 9.5 W (PoE)
Operating Temperature: -22°F to 140°F (-30°C to 60°C); Humidity ≤ 95% (non-condensing)
Ingress Protection Rating: IP67
Form Factor & Finish: Turret / Eyeball, Matte Black Housing
Dimensions (L x W x H): 5.44" × 5.44" × 4.90"
Shipping Dimensions (L x W x H): 6.69" × 6.69" × 5.91"
Weight: 1.65 lbs
Shipping Weight: 2.22 lbs
