Features
Enterprise-Class Lifecycle & Management: Backed by the ASUS Corporate Stable Model (CSM) program with up to a 36-month supply lifecycle, 6-month end-of-life notices, and integrated ASUS Control Center Express software for centralized remote IT endpoint control.
Next-Gen CPU Power Delivery: Features an 8(80A) + 1(80A) + 1(80A) + 1(80A) DrMOS power stage array, a 6-layer PCB, Digi+ VRM control, and ProCool solid-pin power connectors to ensure consistent voltage regulation under sustained multi-threaded workloads.
Advanced DDR5 Memory Overclocking: Employs ASUS Enhanced Memory Profile III (AEMP III) and DIMM Fit/DIMM Fit Pro technologies, maximizing CUDIMM and standard DDR5 signal integrity to hit speeds up to 8666+ MT/s (OC).
High-Speed PCIe 5.0 Graphics & Storage: Includes a PCIe 5.0 x16 SafeSlot for next-generation discrete GPUs and an ultra-fast M.2 slot operating at PCIe 5.0 x4 speeds (up to 128 Gbps) for instantaneous boot times and data transfers.
Low-Latency Hybrid Networking: Combines on-board Wi-Fi 6E with 6 GHz spectrum access and Realtek 2.5Gb Ethernet with ASUS LANGuard protection for stable, interference-free high-speed connectivity.
Intelligent Cooling Controls: Offers comprehensive thermal regulation using enlarged VRM heatsinks, an M.2 heatsink, hybrid 4-pin fan headers, an AIO pump header, and Fan Xpert 2+ software with Auto-Tuning and Extreme Quiet modes.
Streamlined EZ PC DIY Architecture: Accelerates the build process with a pre-mounted I/O shield, snap-in Q-Antenna, Q-LED diagnostic indicators, and Q-Slot retention clips.
Versatile High-Bandwidth I/O: Provides 20 Gbps Type-C connectivity with DisplayPort Alt Mode, multiple USB 10 Gbps and 5 Gbps interfaces, and front/rear expansion for diverse peripheral setups.
Specifications
CPU Socket: Intel Socket LGA1851
Compatible Processors: Intel Core Ultra Processors (Series 2); supports Intel Turbo Boost Technology 2.0 & Turbo Boost Max 3.0
Chipset: Intel B860 Chipset
Memory Support:
4 x DIMM slots, maximum capacity up to 256 GB
DDR5 up to 8666+ MT/s (OC), Non-ECC, Un-buffered, Clocked Unbuffered DIMM (CUDIMM)
Dual-channel architecture, Intel XMP, and ASUS AEMP III support
Graphics Outputs:
1 x DisplayPort 1.4 (supports up to 4K @ 60 Hz)
1 x HDMI 2.1 (supports up to 4K @ 60 Hz)
1 x USB Type-C 20 Gbps port with DisplayPort Alt Mode (supports up to 4K @ 120 Hz)
Expansion Slots:
1 x PCIe 5.0 x16 slot (supports x16 mode via CPU)
1 x PCIe 4.0 x16 slot (supports x4 mode via B860 Chipset)
3 x PCIe 4.0 x16 slots (support x1 mode via B860 Chipset)
Storage Interfaces:
M.2_1 slot (Key M), type 2242/2260/2280 (PCIe 5.0 x4 mode via CPU)
M.2_2 slot (Key M), type 2242/2260/2280/22110 (PCIe 4.0 x4 mode via B860 Chipset)
4 x SATA 6 Gb/s ports (supports SATA RAID 0/1/5/10)
Ethernet: 1 x Realtek 2.5Gb Ethernet with ASUS LANGuard
Wireless & Bluetooth: 2x2 Wi-Fi 6E (802.11ax, 2.4/5/6 GHz bands) + Bluetooth 5.3
Rear I/O Ports:
1 x USB 20 Gbps Type-C (with DP Alt Mode)
2 x USB 10 Gbps Type-A
1 x USB 5 Gbps Type-A
4 x USB 2.0 Type-A
1 x HDMI port
1 x DisplayPort
1 x Wi-Fi Module (Q-Antenna ports)
1 x Realtek 2.5Gb Ethernet port
3 x Audio jacks
Internal Headers:
1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header, 1 x 4-pin AIO Pump header, 4 x 4-pin Chassis Fan headers
1 x 24-pin Main Power connector, 1 x 8-pin +12V CPU Power connector
1 x USB 5 Gbps connector (USB Type-C)
1 x USB 5 Gbps header (supports 2 ports)
1 x USB 2.0 header (supports 2 ports)
3 x Addressable Gen 2 RGB headers, 1 x Aura RGB header
1 x Thunderbolt / USB4 header
1 x SPI TPM header (14-1 pin), 1 x COM Port header, 1 x Clear CMOS header, 1 x Chassis Intrusion header
Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC (up to 24-bit/192 kHz playback, audio shielding, premium capacitors, dedicated PCB layers)
BIOS: 2 x 128 Mb Flash ROM, UEFI AMI BIOS
Operating System Support: Windows 11 (22H2 & later), Windows 10 64-bit (21H2 & later)
Form Factor: ATX Form Factor
Dimensions (L x W x H): 12.0 in. x 9.6 in.
