Intellinet 42U Pro Line Network Cabinet with Integrated Fans (716253)

The Intellinet 42U Pro Line Network Cabinet (716253) is a robust, fully assembled floor-standing rack designed for secure housing of network, server, telecom, and A/V equipment. Constructed from durable SPCC cold-rolled steel with an anti-static powder coating, it offers adjustable mounting rails and reversible, lockable front and rear doors with tempered glass. Enhanced ventilation is provided by a thermostat-controlled, dual-fan unit to maintain optimal operating temperatures. Removable side panels ensure easy access, while pre-installed leveling feet and heavy-duty casters offer stability and mobility. This cabinet includes shelves, blank panels, mounting hardware, and grounding kits, complying with ANSI/EIA 310-D, IEC 60297-2, DIN41494, and ETSI standards.

Features
Security: Features a secure multi-point locking, tempered-glass front door and a lockable steel rear door. Removable side panels are secured with latches.
Ventilation: A roof-mounted, two-fan ventilation unit with a thermostat provides efficient heat dissipation.
Adjustable: The front and rear mounting rails are adjustable from 5.91 in. to 19.69 in. (150 to 500 mm) to accommodate various equipment sizes.
Durability: Constructed from sturdy SPCC cold-rolled steel with an anti-static powder coating for long-lasting performance.
Access: Reversible front and rear doors and removable side panels allow for easy access to cabling and components.
Portability: Includes pre-installed leveling feet and heavy-duty casters for stability and maneuverability.
Accessories: Comes with shelves, blank panels, mounting screws, and grounding kits.
Assembly: Ships fully assembled, saving time on installation.
Compliance: Meets several industry standards, including ANSI/EIA 310-D, IEC 60297-2, DIN41494, and ETSI.

Specifications
Rack Units: 42U
Color: Black RAL 9004
Overall Dimensions (without feet/casters): 23.62" (W) x 23.62" (D) x 78.11" (H)
Material: SPCC Cold-Rolled Steel
Protection Rating: IP20
Maximum Static Load: 1760 lbs. (800 kg); 700 lbs. (320 kg) on casters
Fan Unit Power: 110 VAC, 60 Hz, 0.27 A
Fan Airflow: 86 cfm (146 m³/h) per fan
Fan Noise Level: 46 db (A)
Included Shelves: Nine 2U, vented shelves, each with a 22 lbs. (10 kg) load capacity.
Weight:
Net Weight: 236 lbs. (107 kg)
Gross Weight: 258 lbs. (117 kg)
